Intelligent Computer Casting NDT X Ray Machine With 65W Generator Power UNC130/ Máy x ray Unicomp UNC130 kiểm tra không phá hủy vật đúc

Liên hệ

Mô tả

Product Details:

Place of Origin: China
Brand Name: UNICOMP
Certification: CE
Model Number: UNC130
Detailed Product Description
Maximum Penetration(FE): 50mm Tube Voltage: 130kV
Generator Power: 65W Generator Focal Size: 5μm
Detection Range: Φ300*400mm X-ray Leakage Dose Rate: ≤1uSv/h

Intelligent Aluminum Computer X-ray machine Casting Part Inspection in Laos Iran

Unicomp Technology UNC series X-ray real-time imaging testing equipment is a standardized industrial industry non-destructive testing equipment, Our company have a lot of experience about designing non-standard X-ray and the solution of testing technology program. Help customers about the manufacturing process, research, project development, on the test process to achieve test results, and then make sure product quality.



Compact X-ray system for high-quality, dependable inspection results

Manual and programmable X-ray and computed tomography inspection

True lnspect ADR (automatic defect recognition) for foundry applications

Responsive solution that can be adapted to your special application needs

Review workstation for image evaluation

Data Matrix Code reader for part type recognition

Floor tilt axis for maximum versatility



UNC130 assists you in detection of casting flaws in items such as:

1. Aluminum castings (engine blocks, cylinders, cylinder heads, pistons, knuckles)

2. Turbine blades

3. Fiber-reinforced materials

4. Ceramics

5. 3D printed materials

Technical Data



Attribute Respective Value
Maximum penetration(FE) 50mm
Equipment weight 2T
System Dimension 1602mm*1296mm*2148mm(L*W*H)
X-ray Tube 160KV
Detection range Φ300*400mm
Pixel Pitch 75μm
Focal size 5μm
Image Area 115mm*65mm





Intelligent Computer Casting NDT X Ray Machine With 65W Generator Power
